Stainless Steel Welded Wire Mesh
Stainless Steel welded wire mesh is made of high quality stainless steel wire and welded by advanced computer-controlled machines. It possesses features of excellent corrosion resistance, beautiful look, and longer work time. Compared with galvanized welded iron wire mesh or PVC coated welded iron wire mesh, these features can compensate for its seemingly higher cost. Commonly used material wires are SS304 and SS316.
Application:
With the above-mentioned features, Stainless Steel welded wire mesh is a good choice for fishery industry, food drying, marine use, rodent proofing, cages for animals, and decoration, etc.
Stainless Steel Wire Quality:
For stainless steel welded wire mesh, the material quality control is regarded as the vital importance. We have signed Long-term Buying Contract with the best stainless steel wire manufacturer, this ensures our stainless steel wire is the top quality in China.
Digital Controlled Machines & Well-Trained Staff:
Our Digital Controlled Welding Machines and our well-trained workers also ensure our stainless steel welded wire mesh can satisfy the top quality requirement from worldwide
Stainless Steel welded wire mesh
Roll Width: 24 inch, 36 inch, 1 Meter, 48 inch, or 72 inch.
Roll Length: 100 feet or 150 feet
Note: other roll width or roll length can be made according to request.
Material: Both SS304 and SS316 can be made to the following specifications.

Mesh Size
Wire Gauge Diameter
MM
In Inch
BWG No.
MM
6.4mm
1/4Inch
BWG24-22
0.56mm- 0.71mm
9.5mm
3/8Inch
BWG23-19
0.64mm - 1.07mm
12.7mm
1/2Inch
BWG22-16
0.71mm - 1.65mm
19.1mm
3/4Inch
BWG21-16
0.81mm - 1.65mm
25.4x 12.7mm
1 x 1/2Inch
BWG21-16
0.81mm - 1.65mm
25.4mm
1Inch
BWG21-14
0.81mm - 2.11mm
38.1mm
1 1/2Inch
BWG19-14
1.07mm - 2.11mm
25.4 x 50.8mm
1 x 2Inch
BWG17-14
1.47mm - 2.11mm
50.8mm
2Inch
BWG16-12
1.65mm-2.7mm


SS304 Chemical Composition:           SS316 Chemical Composition:

C - 0.08%                                        C - 0.08%
Cr - 17.0 - 20.0%                           Cr - 16.0 - 18.0%
Mn - 2.0%                                        Mn - 2.0%
Ni - 8.0 - 10.5%                              Ni - 10.0 - 14.0%
P - 0.04%                                         P - 0.04%
S - 0.03%                                        S - 0.03%
Si - 0.75 - 1.00%                           Si - 0.75 - 1.00%

Stainless Steel Welded Wire Mesh  Stainless Steel Welded Wire Mesh
Stainless Steel Welded Wire Mesh  Stainless Steel Welded Wire Mesh
